Supported CPU
AMD Socket AM5, Support For: AMD Ryzen 7000 / Ryzen 8000 Series Processors (Go To GIGABYTE's Website For The Latest CPU Support List.)
Chipset
AMD B650
Memory Type
DDR5
Maximum Memory
up to 192 GB (48 GB single DIMM capacity) of system memory
PCIe Slots
1 X PCI Express X16 Slot (PCIEX16), Integrated In The CPU: - AMD Ryzen 7000 Series Processors Support PCIe 4.0 × 16 Mode - AMD Ryzen 8000 Series-Phoenix 1 Processors Support PCIe 4.0 × 8 Mode - AMD Ryzen 8000 Series-Phoenix 2 Processors Support PCIe 4.0 × 4 Mode * The PCIEX16 Slot Can Only Support A Graphics Card Or An NVMe SSD. If Only One Graphics Card Is To Be Installed, Be Sure To Install It In The PCIEX16 Slot. Chipset: - 1 X PCI Express X1 Slot, Supporting PCIe 3.0 And Running At X1 (PCIEX1)
LAN
Realtek 2.5GbE LAN Chip (2.5 Gbps/1 Gbps/100 Mbps)
Wi-Fi
Realtek Wi-Fi 6E RTL8852CE - WIFI A, B, G, N, Ac, Ax, Supporting 2.4/5/6 GHz Carrier Frequency Bands - BLUETOOTH 5.3 - Support For 11ax 160MHz Wireless (Actual Data Rate May Vary Depending On Environment And Equipment.)
Audio
Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software To configure 7.1-channel audio, access the audio software for audio settings.
